HY-NL Nylon Mesh Pre-filter
Advantage:
* Acid/Alkali resistible
* Washable
* High airflow rate and low airflow resistance
* High temp resistible and damp-proof
Applications:
Pre-filter and foreign material filtration, commercial and industrial ventilation systems
1) It’s used for clean room air conditioning system, which is pre-filtered by fresh air exhaust unit and connected with external air conditioning
2) The pre-filtration of central air-conditioning system and clean room air inlet pre-filtration.
3) It's used for air purification equipment inlet pre-filtration.
4) It’s used for air conditioning air flow distribution filtration
5) It’s used for Primary filtration in the filtration system
Material and Features:
1) Filter media: Nylon net is woven with PP, PA, PE and other monofilaments
2) Inner support frame: galvanized steel and stainless steel wire.
3) Frame: Aluminum Alloy frame/stainless steel frame/non-woven fabric wrapping.
4) Large ventilation capacity. Low airflow resistance, washable, reusable, long life span in humid working condition.
5) Certain corrosion resistance to general solvent, weak acid and weak alkali, to avoid prolonged exposure to ultraviolet light from the sun.
Technical parameters:
Filter object : ≥10μm pre-filtration of particles.
Humidity resistance (relative humidity): ≤100%RH
Temperature resistance: ≤100 ℃
Instantaneous temperature: ≤120 ℃
Specification :
Model | Dimensions | Rates Air Velocity
(m/s) | Rated Air Flow
(m3/h) | Initial Pressure Drop
(Pa) |
H(mm) | W(mm) | T(mm) |
|
HY-NL-7 | 595 | 595 | 7 | 2 | 2500 | ≤50 |
HY-NL-10 | 595 | 595 | 10 |
HY-NL-15 | 595 | 595 | 15 |
HY-NL-21 | 595 | 595 | 21 |
HY-NL-25 | 595 | 595 | 25 |
HY-NL-46 | 595 | 595 | 46 |
Note: Other specifications can be customized |
